Ubiquiti ES-5XP EdgeSwitch 5-Port PoE 60W Gigabit Managed Switch

Name: Ubiquiti ES-5XP EdgeSwitch 5-Port PoE 60W Gigabit Managed Switch
Brand: Ubiquiti
SKU: ES-5XP
Price: 1558.0 MAD
Availability: OutOfStock

Ubiquiti ES-5XP EdgeSwitch 5-Port PoE 60W Gigabit Managed Switch

1 558 Dhs

~~0 Dhs~~ 1 558 Dhs

En vente Épuisé

Variantes de produits

Quantité

Livraison gratuite nationale pour toute commande supérieure à 1500 Dhs

Garantie 7 jours retours
Commandez avant 12h00 pour une expédition sous 24h
Paiement à la livraison

EdgeSwitch 5XP 24V PoE - Advanced Power over Ethernet Switch [ES-5XP]

The EdgeSwitch® XP delivers reliable passive PoE and Gigabit connectivity to attached Ubiquiti devices and other devices that support passive PoE.

Introducing the Advanced Power over Ethernet Switches, EdgeSwitch™ XP from Ubiquiti Networks. EdgeSwitch XP delivers reliable passive PoE and fast 10/100/1000 Mbps connectivity to attached Ubiquiti devices and other devices that support passive PoE.

To connect your PoE devices, simply enable PoE in the easy-touse EdgeSwitch XP Configuration Interface. Each port can be individually configured to provide PoE, so both PoE and non‑PoE devices can be connected. EdgeSwitch XP is available in multiple versions to meet your deployment needs.

EdgeSwitch 5XP is a cost‑effective, 5-port Gigabit switch with 24V PoE support.
EdgeSwitch 8XP is an industrial strength, 8-port Gigabit switch with 150 watts of power capable of powering 24V or 48V devices. Output voltage is controlled by the software.
EdgeSwitch 16XP features dual EdgeSwitch 8XP systems in a rack‑mountable, 1U form factor with 300 watts of power supporting up to 16 devices.

Specifications

Mechanical
Dimensions	197 x 87.5 x 27.3 mm (7.8 x 7.8 x 1.6")
Weight	250 g (8.8 oz)
Hardware
Processor	MIPS 24K, 400 MHz
System memory	64 MB
Code storage	8 MB
Networking interface	(5) 10/100/1000 Ethernet ports
Management interface	(1) 10/100 Ethernet port
Power method	24V DC, 2.5A power adapter (Included)
Max. power consumption	60W
PoE Out voltage range	22-24V DC
Max. PoE wattage per port	11.5W
ESD rating	Air/contact: ±24 kV
PoE method	Passive
Button	Factory reset
PoE configurable per port	Management port: N/A Data ports: Off/24V
LEDs	Management port: power/link Data ports: PoE, speed/link/activity
Ambient operating temperature	-25 to 55° C (-13 to 131° F)
Ambient operating humidity	10 to 90% noncondensing
Certifications	CE, FCC, IC
