Massively Expanded Device Capacity
Less Loading Wheels
Enjoy smooth gaming, video streaming, and life feeds simultaneously. OFDMA makes your WiFi stronger by allowing multiple clients to share one band simultaneously, which cuts latency and jittering.
Reliable Connections and Less Latency
Enjoy fast connections with minimal latency even under the heaviest loads, thanks to the advanced Qualcomm chipset and high-speed memory. Every click on a website and response from online gaming responds quicker.
Specifications
Category | Details |
---|---|
Wireless | |
Standards | Wi-Fi 6 |
- IEEE 802.11ax/ac/n/a 5 GHz | |
- IEEE 802.11ax/n/b/g 2.4 GHz | |
WiFi Speeds | AX3000 |
- 5 GHz: 2402 Mbps (802.11ax, HE160) | |
- 2.4 GHz: 574 Mbps (802.11ax) | |
WiFi Range | 3 Bedroom Houses |
- 4× Fixed High-Performance Antennas | |
- Beamforming: Concentrates wireless signal strength towards clients to expand WiFi range | |
- High-Power FEM: Improves transmission power to strengthen signal coverage | |
WiFi Capacity | High |
- Dual-Band: Allocate devices to different bands for optimal performance | |
- OFDMA: Simultaneously communicates with multiple Wi-Fi 6 clients | |
- Airtime Fairness: Improves network efficiency by limiting excessive occupation | |
- DFS: Access an extra band to reduce congestion | |
- 4 Streams: Connect your devices to more bandwidth | |
Working Modes | - Router Mode |
- Access Point Mode | |
Security | |
Network Security | - SPI Firewall |
- Access Control | |
- IP & MAC Binding | |
- Application Layer Gateway | |
HomeShield Security | - Real-Time IoT Protection |
- Malicious Site Blocker | |
- Intrusion Prevention System | |
- DDoS Attack Prevention | |
- Home Network Scanner | |
Guest Network | - 1× 5 GHz Guest Network |
- 1× 2.4 GHz Guest Network | |
VPN Server | - OpenVPN |
- PPTP | |
- L2TP | |
VPN Client | - OpenVPN |
- PPTP | |
- L2TP | |
WiFi Encryption | - WPA3* |
- WPA2 | |
- WPA | |
- WPA/WPA2-Enterprise (802.1x) | |
Hardware | |
Ethernet Ports | - 1× 2.5 Gigabit WAN/LAN Port |
- 1× Gigabit WAN/LAN Port | |
- 3× Gigabit LAN Ports | |
USB Support | 1× USB 3.0 Port |
Supported Partition Formats | NTFS, exFAT, HFS+, FAT32 |
Buttons | - Wi-Fi/WPS Button |
- Power On/Off Button | |
- Reset Button | |
Power | - 12 V/ 2 A (US Version) |
- 12 V/ 1.5 A (EU Version) | |
Software | |
Protocols | - IPv4 |
- IPv6 | |
Service Kits | - HomeShield |
OneMesh™ | - OneMesh™ Supported |
EasyMesh | - Mesh networking creates smooth, fast, stable roaming |
Parental Controls | - HomeShield Parental Controls |
WAN Types | - Dynamic IP |
- Static IP | |
- PPPoE | |
- PPTP | |
- L2TP | |
Quality of Service | - QoS by Device |
Cloud Service | - Auto Firmware Upgrade |
- OTA Firmware Upgrade | |
- TP-Link ID | |
- DDNS | |
NAT Forwarding | - Port Forwarding |
- Port Triggering | |
- DMZ | |
- UPnP | |
IPTV | - IGMP Proxy |
- IGMP Snooping | |
- Bridge | |
- Tag VLAN | |
DHCP | - Address Reservation |
- DHCP Client List | |
- Server | |
DDNS | - TP-Link |
- NO-IP | |
- DynDNS | |
Management | - Tether App |
- Webpage | |
Other | |
System Requirements | - Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser |
- Cable or DSL Modem (if needed) | |
- Subscription with an internet service provider (for internet access) | |
Certifications | - FCC, CE, RoHS |
Environment | - Operating Temperature: 0℃~40℃ (32℉ ~104℉) |
- Operating Humidity: 10%~90% non-condensing |
