APC Smart-UPS SC 450VA 230V 1U Rackmount/Tower - SC450RMI1U

Overview

APC Smart-UPS SC is ideal for small and medium businesses looking to protect networking equipment and point-of-sale (POS) devices from power disturbances and outages. The Smart-UPS SC features network grade protection, hot swap batteries, and built-in data line protection for worry free uninterruptible power protection for increased availability. Built on the same standards as the award-winning Smart-UPS, Smart-UPS SC provides the basic features and manageability needed to protect entry-level applications

Specifications

Main Input Voltage	230 V
Main Output Voltage	230 V
Rated power in W	280 W
Rated power in VA	450 VA
Input Connection Type	IEC 320 C14
output connection type	4 IEC 320 C13 2 IEC Jumpers
Number of rack unit	1U
Battery type	Lead-acid battery
Provided equipment	User manual Rack mounting brackets Smart UPS signalling RS-232 cable CD with software
Battery voltage	12 V
Extended runtime	0
Battery capacity	9.0 Ah
Number of battery filled slots	0
Number of battery free slots	0
Battery recharge time	5 h
Number of battery replacement quantity	1
Battery life	3…5 year(s)
Replacement battery	RBC18
Battery power in VAH	108 VAh runtime
Battery charger power	22 W rated
Number of power module filled slots	0
Number of power module free slots	0
product web sub-family	Entry level
Redundant	No
Colour	Grey
Height	4.4 cm
Width	43.2 cm
Depth	38.3 cm
Net weight	10.18 kg
Mounting location	Front
Mounting preference	Lower
Mounting mode	Rack-mounted
Two post mountable	0
USB compatible	No
Input voltage limits	151...302 V adjustable 195...265 V
Network frequency	50/60 Hz +/- 3 Hz auto-sensing
Harmonic distortion	Less than 5 % at full load
Maximum configurable power in VA	450 VA
Maximum configurable power in W	280 W
Transfer time	4 ms typical : 8 ms maximum
UPS type	Line interactive
Wave type	Stepped approximation to a sinewave
Output frequency	47...53 Hz for 50 Hz nominal sync to mains 57...63 Hz for 60 Hz nominal sync to mains
Product certifications	C-Tick CE EAC GOST TISI VDE
Standards	EN/IEC 62040-1:2019/A11:2021 EN/IEC 62040-2:2006/AC:2006 EN/IEC 62040-2:2018
Acoustic level	38 dBA
Heat dissipation	38 Btu/h
Operating altitude	0...10000 ft
Ambient air temperature for operation	0…40 °C
Ambient air temperature for storage	-15…45 °C
Storage altitude	0.00…15240.00 m
Relative humidity	0…95 %
Storage Relative Humidity	0…95 %
Emergency power off	Optional
Free slots	0
Control panel	LED status display with on line : on battery : replace battery and overload indicators
Alarm	Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Data line protection	RJ45 10/100 Base-T Ethernet protection
Data line protection	RJ11 2-Way Modem/Fax/DSL splitter with protection (four wire dual line)
Surge energy rate	320 J
Noise suppression	Full time multi-pole noise filtering : 0.7% IEEE surge let-through : zero clamping response time : meets UL 1449
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	16.4 cm
Package 1 Width	47.6 cm
Package 1 Length	58.9 cm
Package 1 Weight	11.73 kg
Unit Type of Package 2	PAM
Number of Units in Package 2	32
Package 2 Height	143.8 cm
Package 2 Width	100 cm
Package 2 Length	120 cm
Package 2 Weight	403.2 kg
